HEIDELBERG QM DI 46-4 MACCHINA DA STAMPA

HEIDELBERG QM DI 46-4 MACCHINA DA STAMPA ANNO 2000 4 Color Low Pile Delivery 13x19" Harlequin 5.3 Rip Purchased Refurbished From Heidelberg USA Functions Perfectly - Ready To Print Specifications Formats Max. Sheet format: 460 mm x 340 mm (18 1/8? x 13 3/8?) Min. Sheet format: 140 mm x 89 mm (5 ½” x 3 1/2?) Largest printable area: 450 x 330 nun (173/4? x 13?) Gripper margin: 10 mm (13/32?) Stock thickness: 0.06 to 0.30 mm (0.0016? to 0.012?) Printing Plates Presstek PEARL dry, multilayer masters for thermal imaging on supply reel, polyester base material. 35 Plates per Roll Production speed Max. Production run speed: 10,000 sph Min. Production nm speed: 3,500 sph Pile heights Feeder: 490 nun (2’7 / 14?) Delivery: 450 mm (1 ’5 3/4?) Direct Imaging Imaging resolutions: 1,270 dpi / 2,540 dpi Imaging times: < 4 min. at 1,270 dpi Laser diodes per printing unit: 16 Blanket cylinders Length x width, metal edged: 555 mm x 337 nun (21 7/8? x 13 1/4?) Thickness: 1.95 mm (0.077?) Blanket cylinder undercut: 2.3 mm (0.091?) Inking unit No. rollers: 12 (inc1. fountain roller) Form rollers: 3 No. of Ink Keys: 8 Diameter of form rollers: 54.7-45-50 mm (2 l/8?-1 3/4?-2?) About the press Dimensions (length x width x height): 245 x 255 x 190 cm (8' 1/2? x 8' 4 1/2? x 6’3 l/2?) Weight: 3,800 kg (8,378Ibs.) info. francesco pizzolorusso 333/7819083 pizzocar 0883/541041 tutti i mezzi della pizzocar sono presenti e pronta consegna con libretto e certificato di proprieta'a noi intestato.
